Zone Air® DIY 9,000 BTU 24 SEER2 230V Wall Mount Ductless Mini-Split Heat Pump AC and Heater with Pre-Charged Lineset - Up to 450 Sq Ft
$1,949.99
Sale price
$1,949.99
Regular price
Skip to product information
Zone Air® DIY 9,000 BTU 24 SEER2 230V Wall Mount Ductless Mini-Split Heat Pump AC and Heater with Pre-Charged Lineset - Up to 450 Sq Ft
$1,949.99
Sale price
$1,949.99
Regular price
The 230V version of our 9K BTU system delivers maximum efficiency with a 24 SEER2 rating. Ideal for single rooms from 250-450 square feet where 230V power is available. Perfect for bedrooms, offices, additions, and commercial applications.
Specifications
| Power Supply | 208~230V, 60Hz, 1Ph |
|---|---|
| Cooling Rated Capacity | 9,000 BTU/h |
| Cooling Capacity Range | 2,500~12,500 BTU/h |
| Cooling SEER2 | 24.0 |
| Cooling EER2 | 13.0 |
| Heating Rated Capacity | 9,400 BTU/h |
| Heating Capacity Range | 2,500~15,000 BTU/h |
| Heating HSPF2 (Region IV/V) | 10.0 / 8.6 |
| Heating COP2 (47°F/5°F) | 3.81 / 2.1 |
| Refrigerant Type | R454b (pre-charged) |
| Recommended Room Size | 250~450 sq ft |
| Minimum Room Size | 40 sq ft |
| Piping Diameter | 3/8" (Gas) / 1/4" (Liquid) |
| Indoor Air Flow (Turbo/Hi/Med/Lo/Mute) | 500 / 470 / 411 / 323 / 205 CFM |
| Indoor Sound Level (Turbo/Hi/Med/Lo/Mute) | 46 / 44 / 36 / 32 / 30 dB(A) |
| Indoor Unit Dimensions (WxDxH) | 36-1/2" x 7-5/8" x 12" |
| Indoor Unit Weight | 23.1 lbs |
| Breaker Needed | 15A (double-pole) |
| Outdoor Sound Level | 52 dB(A) |
| Outdoor Unit Dimensions (WxDxH) | 31-7/8" x 12" x 21-5/8" |
| Outdoor Unit Weight | 58.4 lbs |
| Lineset Length Included | 16 ft |
| Part Number | zdiy-mk1-9I-230 |
| Air Flow (Turbo/Hi/Med/Lo/Mute) | 500 / 470 / 411 / 323 / 205 CFM |
| Sound Level (Turbo/Hi/Med/Lo/Mute) | 46 / 44 / 36 / 32 / 30 dB(A) |
| Net Dimensions (WxDxH) | 36-1/2" x 7-5/8" x 12" |
| Carton Dimensions (WxDxH) | 39" x 10-1/2" x 15" |
| Net / Gross Weight | 23.1 / 30.9 lbs |
| Sound Level | 52 dB(A) |
