Zone Air® DIY 12,000 BTU 23 SEER2 115V Wall Mount Ductless Mini-Split Heat Pump AC and Heater with Pre-Charged Lineset - Up to 600 Sq Ft
$1,999.99
Sale price
$1,999.99
Regular price
Skip to product information
Zone Air® DIY 12,000 BTU 23 SEER2 115V Wall Mount Ductless Mini-Split Heat Pump AC and Heater with Pre-Charged Lineset - Up to 600 Sq Ft
$1,999.99
Sale price
$1,999.99
Regular price
Ideal for spaces from 350-600 square feet including master bedrooms, home offices, and living areas. This system combines exceptional efficiency with whisper-quiet operation and delivers powerful heating even in extreme cold.
Specifications
| Power Supply | 110-120V, 60Hz, 1Ph |
|---|---|
| Cooling Rated Capacity | 12,000 BTU/h |
| Cooling Capacity Range | 2,500-12,500 BTU/h |
| Cooling SEER2 | 23.0 |
| Cooling EER2 | 13.0 |
| Heating Rated Capacity | 12,400 BTU/h |
| Heating Capacity Range | 2,500-15,000 BTU/h |
| Heating HSPF2 (Region IV/V) | 10.0 / 8.6 |
| Heating COP2 (47°F/5°F) | 3.81 / 2.1 |
| Refrigerant Type | R454b (pre-charged) |
| Recommended Room Size | 350~600 sq ft |
| Minimum Room Size | 40 sq ft |
| Piping Diameter | 3/8" (Gas) / 1/4" (Liquid) |
| Indoor Air Flow (Turbo/Hi/Med/Lo/Mute) | 500 / 470 / 411 / 323 / 205 CFM |
| Indoor Sound Level (Turbo/Hi/Med/Lo/Mute) | 46 / 44 / 36 / 32 / 30 dB(A) |
| Indoor Unit Dimensions (WxDxH) | 36-1/2" x 7-5/8" x 12" |
| Indoor Unit Weight | 23.1 lbs |
| Breaker Needed | 15A (single-pole) |
| Outdoor Sound Level | 52 dB(A) |
| Outdoor Unit Dimensions (WxDxH) | 31-7/8" x 12" x 21-5/8" |
| Outdoor Unit Weight | 58.4 lbs |
| Lineset Length Included | 16 ft |
| Part Number | zdiy-mk1-12I |
| Air Flow (Turbo/Hi/Med/Lo/Mute) | 500 / 470 / 411 / 323 / 205 CFM |
| Sound Level (Turbo/Hi/Med/Lo/Mute) | 46 / 44 / 36 / 32 / 30 dB(A) |
| Net Dimensions (WxDxH) | 36-1/2" x 7-5/8" x 12" |
| Carton Dimensions (WxDxH) | 39" x 10-1/2" x 15" |
| Net / Gross Weight | 23.1 / 30.9 lbs |
| Sound Level | 52 dB(A) |
